Greenhouse picking scissor lift is mainly used for fruit harvesting of high-rise crops such as tomatoes, cucumbers, peppers, etc. in greenhouse facilities, crop pruning, artificial pollination and other agricultural operations. It has the advantages of small size, low noise, stepless speed regulation, simple structure, easy operation, zero emission, no pollution, etc. Compared with manual operation, the work efficiency can be increased by more than 10 times.

This product relies on electric drive to move forward and backward and brake steplessly on the greenhouse track. The workbench can realize automatic control of hydraulic lifting and operate in the narrow working channel of the greenhouse.

The track picking car is one of the necessary equipment in the cultivation and production of modern greenhouse vegetables, which is convenient for pruning, pruning, harvesting and other links after the plant. It is specially designed for planting tomatoes, peppers, cucumbers and other vegetables in greenhouses. It can meet the pollination, hanging, picking and other operations of fruits at all angles and heights. It is stable to drive and has low maintenance cost, which is a good helper for modern facility agriculture.

The design is ergonomic, easy to operate, and equipped with a foot switch for more convenient and flexible movement. It is safe and reliable, with complete protective measures, equipped with an emergency descent function, a sturdy safety rail at the bottom, a tilt alarm function, a brake system, and can support supporting columns.

Flexible transfer, the bottom of the equipment is equipped with 4 flange wheels to ensure its smooth movement along the track, and is equipped with 4 rubber tires so that it can travel along the cement road. The picking car moves forward and backward longitudinally to achieve stepless speed regulation.

The lifting platform is driven by a hydraulic lifting system to achieve smooth and continuous vertical lifting. The system is flexible and can automatically and smoothly adjust the height. If the lifting is not used for a long time, the main switch can be turned off.

The equipment is equipped with two control panels. The control panel on the operating table is equipped with an emergency stop switch, a direction switch and a speed control switch. The lifting and translation of the operating platform can also be controlled. There is a 24V output power supply on the control panel, which can be connected to a fan or lighting.

Specification

Main configuration:

Curtis drives imported from the United States

Renowned brand power type maintenance free batteries

Italian imported drive motor

Famous brand hydraulic power unit

Hydraulic seals imported from Japan

Famous brand smart charger
