Diesel

boom lift straight arm GTBZ-32J 38J 56J

For product pricing, customization, or other inquiries:

CONTACT US

Share to:

Description

Reach New Heights with Our Self-Propelled Telescopic Boom Lift!


Introducing the ultimate solution for all your elevated work needs—the Self-Propelled Telescopic Boom Lift. Engineered for versatility, efficiency, and safety, this boom lift empowers you to tackle even the most challenging jobs with ease.


Key Features:

Extended Reach: With a telescopic arm that extends up to [specific height], you can access hard-to-reach areas effortlessly.

Self-Propelled Mobility: Navigate through tight spaces and rough terrains smoothly, thanks to its robust self-propelled design.

Enhanced Safety: Equipped with state-of-the-art safety features including automatic leveling, emergency stop functions, and fall protection systems.

User-Friendly Controls: Operate with precision and ease using intuitive control panels and joystick functionality.

Durable Construction: Built to withstand tough working conditions, our boom lift ensures long-lasting performance and reliability.

Applications:

Construction Sites: Ideal for high-rise building projects, maintenance, and inspections.

Warehousing: Perfect for inventory management, equipment installation, and overhead repairs.

Outdoor Maintenance: Great for tree trimming, billboard installations, and more.

Experience the difference with our Self-Propelled Telescopic Boom Lift. Maximize productivity, enhance safety, and conquer new heights with confidence.



Specification



ModelGTBZ-32JGTBZ-38JGTBZ-56J
Working height maximum 34m 40.2m58m
Platform height maximum 32m 38.2m56m
Horizontal height maximum 22m 21.4/25.4m26m
Length -stowed[D] 14.02m 14m14.9m
Width-stowed[E] 2.49m 2.49m2.49m
Height-stowed[C] 3.08m 3.14m3.15m
Platform size(L*W)[A*B] 2.44m*0.91m 2.44m*0.91m2.44*0.91m
Wheel base[F] 3.66m 4.17m5.6m
Ground clearance[G] 0.47m0.48m380mm
Lift capacity 300Kg/460kg300kg/460kg 300kg/480Kg
Max platform occupancy 222
Drive speed-stowed(max) 4.8km/h4.6km/h 4.4km/h
Drive speed-raised(max) 1.1km/h1.1km/h 1.1m/h
Gradeability-stowed 45%40%40%
Turning radius-inside 2.7m2.94m 2.69m
Turning radius-inside 4.148m 7.6m
Turning radius-outside 6.2m6.2m 7.07m
Turning radius-outside 6.5810m 10m
Turning tail-swing1.8m1.8m 2.5m
Working slope maximum 5 °5 °5°
Tyre 385/65-24445/50D710455/65-22.5
Power source Cummins Cummins Cummins/74KW
Feul Tank170L170L200L
Drive & steering 4WD*4WS4WD*4WS4WD*4WS
Sound pressure level(ground workstation)≤82dBA≤82dBA≤82dBA
Standard weight20950kg22900kg27500kg
